Piston Hyundai 1.2L 71MM 1.0×1.2×2.0MM i10 i20 Kappa 23041-03140

Description

Processing and customization: No
Brand: ZE
Model: 23041-03140
Applicable models: Hyundai Kia i10, i20
Diameter: 71mm (mm)
Number of ring grooves: 3
Piston ring structure: steel belt combined oil ring
Piston ring cross-sectional shape: barrel ring
Surface hardness: greater than 450HV
Material: M142
Origin: Hebei
Cylinder strength: 71
Bore size: 71mm
Cylinder type: in-line four-cylinder
Part number: 23041-03140
Applicable car series: HYUNDAI KIA
Applicable models: i10, i20 engines
Pin hole × pin length: 18*47.5 (mm) (mm)
Compression height: 26.2mm (mm)
General tolerances according to: national standards
Oil ring: 2.0
Center hardness: greater than 300hv
Overall height: 44.2mm (mm)
Applicable models: Hyundai Kia i10, i20
Supporting relationship: applicable
Item number: 23041-03140
Applicable car brands: HYUNDAI
Applicable vehicle transmission type: MT/manual transmission
Main downstream platforms:
ebay, Amazon, wish, AliExpress, independent station, LAZADA
Main sales areas:
Africa, Europe, South America, Southeast Asia, North America, Northeast Asia, Middle East
Is there a licensable private label: No
Whether to provide exclusive supply for cross-border exports: Yes
​
