OUJIAXIN Spare parts For 2.8L I suzu JIANGXI JE4D28A

ENGINE ISUZU JE4D28A

Category: Tag:

Description

The JE4D28A engine adopts advanced electronic control system and high-pressure common rail technology. Its maximum output power is 280 horsepower, maximum torque is 1100 Nm, and maximum speed is 2100 rpm. The displacement of the engine is 7.8L, the cylinder diameter is 114mm, and the stroke is 135mm. It adopts all-aluminum alloy cylinder block and adjustable camshaft technology, which greatly reduces the weight and noise of the engine, and improves the transmission efficiency and reliability.

The JE4D28A engine also adopts high-efficiency fuel injection system and oxygen sensor technology, which can adjust the fuel injection volume and intake air volume in real time according to different working conditions, so as to achieve the best fuel efficiency and emission control effect. The engine is also equipped with Bosch electronic control system and IGR high-power generator, which can realize intelligent control and management, and improve the power performance and economic performance of the whole vehicle.

Advantages of JE4D28A engine

1. High efficiency and economy: JE4D28A engine is characterized by high efficiency and economy, and its fuel economy, power and reliability have reached the international advanced level. During the running process, the fuel consumption can be reduced, and the cost of using the vehicle can be reduced.

2. Environmental protection and energy saving: JE4D28A engine adopts advanced low-emission technology and electronic control system, which can effectively reduce emissions, meet national environmental protection standards, and reduce the impact of pollution on the environment.

3. High reliability: JE4D28A engine has reasonable engine structure design, stable performance, strong durability of parts and long service life, which can ensure the reliability and reliability of the engine.

4. Intelligent: JE4D28A engine adopts Bosch electronic control system and IGR high-power generator. Through intelligent control and management, intelligent operation and management of the engine can be realized, which improves the safety and comfort of the vehicle.

Engine model: JE4D28A

Engine brand: Jiangxi Isuzu

Engine series: VM series

Applicable range: MPV, light truck, light bus, minibus

Intake form: supercharged

Number of cylinders: 4

Displacement: 2.776L
Emission standard: National IV
Maximum output power: 103kW
Maximum horsepower: 140 horsepower
Maximum torque: 360N.m
Minimum fuel consumption rate at full load: ≤210g/kW.h
Engine form: in-line, water-cooled, common rail, supercharged, four-stroke
Engine net weight: 250kg
Engine size: 766x653x795mm
Compression ratio: 17.5:1
Bore x stroke: 94x100mm
