OUJIAXIN Motor GEN3 1.8T CUF CUFA EA888 For VW Teramont TiguanL CC MATOGAN GOLF

Description

The EA888 engine is the family of three- and four-cylinder engines currently used by the Volkswagen Group. The EA888 series are units designed by the company VAG and are an evolution of the earlier EA827/113 units. It incorporates some of the latest engine technologies such as direct fuel injection, sintered camshaft lobes, thin-walled engine blocks, variable valve timing and lift for intake and exhaust valves, downstream oxygen sensors, exhaust manifolds integrated into the cylinder heads, exhaust gas recirculation and cooling, distributor coil ignition, lightweight engine internals, spool valve thermostats (on some models) and increased port fuel injection to help reduce load fuel consumption and cold start emissions. Port fuel injection also helps reduce potential carbon deposits that can occur in direct injection engines. As of 2016, the “Dual Injection” system is not available in the North American market. Still, VAG made a number of improvements to its engine design, such as positive crankcase ventilation, repositioning the injectors, etc., to reduce the likelihood of carbon buildup on the intake valves. Currently, the EA888 engine is available in two sizes, 1.8T and 2.0T. Engine outputs range from 111 kW (151 PS; 149 bhp) to over 231 kW (314 PS; 310 bhp). Based on the Volkswagen Golf R concept car, called the R400, it produced 395 horsepower from 2 liters of displacement. Furthermore, thanks to the haldex 4-wheel drive system coupled with a 6-speed or 7-speed DSG gearbox, the R400 is capable of accelerating from 0 to 100 km/h in just 3.8 seconds.

Take Tiguan as an example.
The 1.8T engine has a maximum power of 118kW and a maximum torque of 250Nm.
The engine is mated to a 6-speed manual or 6-speed automatic transmission.
