Original Japanese Rav4 Matrix engine 2.0 2.4 engine 1az 2az complete engine assembly suitable for Toyota Corolla Celica Camry

The Toyota AZ engine range is a family of inline 4-piston engines. The AZ series uses an aluminum engine block, cast iron cylinder liners and aluminum DOHC cylinder heads. The engine family incorporates a number of advanced technologies, including tilt-squeeze combustion chambers, offset cylinder and crankshaft centers, and VVT-i continuously variable intake valve timing. The aluminum engine is 626 mm (24.6 in) long, 608 mm (23.9 in) wide and 681 mm (26.8 in) high.

Category: Tag:

Description

1AZ-FE: The 1AZ-FE is 2.0 L (1,998 cc). The Camry Aurion version develops 108 kW (145 hp) at 6000 rpm and 190 N·m (140 lb·ft) of torque at 4000 rpm. Rav4 and Ipsum engines are rated at 148–150 hp (110–112 kW) at 6000 rpm and 142 lb·ft (193 N·m) at 4000 rpm.

The 1AZ has a total displacement of 2.0 L (1,998 cc), a bore and stroke of 86 mm × 86 mm (3.39 in × 3.39 in), and a compression ratio of 9.6:1.

application:
2002-2006 Toyota Camry (Southeast Asia/Taiwan version)
2006–2009 Toyota Camry (Aurion Edition)
2000–2003 Toyota RAV4
2003-2006 Toyota RAV4 European version
2001–2009 Toyota Ipsum
2004–2008 Toyota Wish (Southeast Asia/Taiwan version)

Other models:

1AZ-FSE: The 1AZ-FSE is 2.0 L (1,998 cc). Bore and stroke are 86 mm × 86 mm (3.39 in × 3.39 in), and the compression ratio is 11.0:1. Power output is 149 PS (110 kW; 147 hp) at 5700 rpm and torque is 196 N·m (145 lb·ft) at 4000 rpm. The 1AZ-FSE features Toyota’s D-4 direct injection system.

application:
Toyota Evans
Toyota Avensis Verso
Toyota Noah/Voxy
Toyota RAV4
Toyota Gaia
Toyota Isis
Toyota Ipsen
toyota cardina
toyota hope
Toyota Nadia
Toyota Allion
Toyota Premio
Toyota Opal

2AZ-FE: The 2AZ-FE is 2.4 L (2,362 cc) with a total displacement of 2.4 L (2,362 cc), a bore and stroke of 88.5 mm × 96 mm (3.48 in × 3.78 in), and a compression ratio of 9.6:1. Output is 160 hp (119 kW) at 5600 rpm; torque is 220 N·m (162 lb·ft) at 4000 rpm.

application:
2002–2011 Toyota Camry in Australia. ACV40R
2009–2011 Toyota Matrix S (USA)/XR (Canada)/XRS
2009–2010 Pontiac Vibe
2009–2010 Toyota Corolla XRS (sold only in Mexico and Canada 2011–2013)
2002–2008 Toyota Camry Solara
2004–2012 Toyota RAV4
2000–2007 Toyota Highlander/Kluger
2000−2013 Toyota Harrier
2000-2019 Toyota Estima / Toyota Previa / Toyota Tarago
2001-2010 Toyota Ipsen
2002−2015 Toyota Alphard
2008−2015 Toyota Vellfire
2006−2012 Toyota Blade
2003-2009 Toyota Ansi
2005–2010 Scion tC
2008–2015 Sion xB
2007-2013 Toyota Mark X ZiO

2AZ-FSE: The 2AZ-FSE is 2.4 L (2,362 cc). Bore and stroke are 88.5 mm × 96 mm (3.48 in × 3.78 in), and the compression ratio is 11.0:1. Output is 163 PS (120 kW; 161 hp) at 5800 rpm and torque is 231 N·m (170 lb·ft) at 3800 rpm. The 2AZ-FSE features Toyota’s D-4 direct injection system.

application:
Toyota Evans

2AZ-FXE: 2AZ-FXE is the Atkinson cycle variant of 2AZ-FE. It has the same bore and stroke, but the intake cam and piston are unique. Its physical compression ratio is 12.5:1.

application:
2003–2014 Toyota Alphard Hybrid
Toyota Estima Hybrid
2007–2011 Toyota Camry Hybrid AHV40
2010–2014 Lexus HS 250h
2009 – Toyota Race
