New original factory CVVT 1.8L JL4G18 Engine For Geely Emgrand Vision GX7

Description

1 Model CVVT-JL4G18 2 Model in-line four-cylinder, four-stroke, water-cooled, double overhead camshaft (DOHC), 16 valves, intelligent continuously variable intake phase CVVT 3 Combustion chamber type single-slope roof-ridge type combustion chamber 4 Electric Control system type No distributor, group ignition, multi-point sequential injection 5 Bore (mm) × stroke (mm) 79 × 91.4 6 Total displacement (L) 1.792 7 Compression ratio 10:1 8 Maximum power (Kw/r/min ) 102/6000~6200 9 Maximum torque (Nm/r/min) 172/4100~4300 10 Minimum full load fuel consumption rate (g/Kw h) ≤260 11 Minimum no-load stable speed (idle speed) (r/min ) 800±50 (1000±50 when the air conditioner A/C is ON) 12 Pollutant emission at idle speed EUⅢ 13 Effective ignition sequence 1-3-4-2 (1, 4 cylinders and 2, 3 cylinders group ignition) 14 Spark plug electrode gap ( mm) 15 Valve clearance (cold state) (mm) Intake valve 0.23±0.03 Exhaust valve 0.32±0.03 16 Fuel grade No. 93 and above unleaded gasoline for vehicles 17 Lubrication method pressure and splash 18 Engine oil grade SAE10W-30, API Quality grade above SG (SAE5W-30 in cold winter regions) 19 Oil capacity (L) 4 (dry full) 20 Oil consumption rate (g/Kw h) ≤2.2 21 Oil pressure (Kpa) Idle speed ≥60 ≥3000r/min 294~539 22 Cooling method Forced circulation water cooling 23 Coolant capacity (L) (with liquid storage tank) 6.0 24 Starting method Electric starter 25 Gasoline engine dry mass (Kg) 111.7 26 Dimensions (length mm×width mm×height mm) 631×610×620
