IVECO SOFIM engine8140 series 2.5 2.8
Iveco SOFIM8140.43S5 129 horsepower 2.8L 2.5 National V diesel engine
Description
In 1990, a longer stroke 2.5L engine was introduced, with stroke increased by 2mm to 92mm. The bore remains the same at 93mm, and this version displaces 2,499 cubic centimeters (152.5 cubic inches).
Engine type: 8140.07 Displacement cc: 2499
Max power
PS (kW) at rpm: 75 PS (55 kW)/4200
76 PS (56 kW)/4000
Max torque
Nm (lb.ft) at rpm: 162 N⋅m (119 lb⋅ft)/2200
165 N⋅m (122 lb⋅ft)/2400
Layout and number of cylinders:R4, DI, naturally aspirated
Valve /number of valves: OHC/8
Car: Fiat Ducato
Iveco TurboDaily
Renault Trafic
Renault Master
Renault Messenger
Tarpan Honker
Years of production: 1989-1994
1990-1994
1990-1994
1990-1997
1990-1999
1991-1996
Engine type: 8140.47 Displacement cc:2499
Max power
PS (kW) at rpm:116 PS (85 kW)/3800
Max torque
Nm (lb.ft) at rpm:245 N⋅m (181 lb⋅ft)/2000
Layout and number of cylinders:R4, DI, turbocharged, intercooled
Valve /number of valves:OHC/8
Car:Fiat Ducato
Iveco TurboDaily
Renault Messenger
Years of production:1994-2002
1994-2000
1994-1996
The 2.8 L displaces 2800 cc having a larger bore and stroke (94.4 x 100 mm).
Engine type：8140.43N Displacement cc:2799
Max power
PS (kW) at rpm:146 (107)/3600
Max torque
at rpm:310 N⋅m (229 lb⋅ft) /1500
320 N⋅m (236 lb⋅ft) /1500
Layout and number of cylinders:R4, DI, Common Rail, turbocharged, intercooled
Valve /number of valves:OHC/8
Car:Fiat Ducato
Citroën Jumper
Peugeot Boxer
Iveco Daily
Renault Mascott
Years of production:2000-2005
2000-2005
2000-2005
2000-2006
2000-2004
